A time switch (also called a timer switch, or simply timer) is a timer that operates an electric switch controlled by the timing mechanism . ... The switch may be connected to an electric circuit operating from mains power, including via a relay or contactor; or low voltage, including battery-operated equipment in vehicles
Specification:
Item No. DQ001
Type of Contacts 1NO
Rated Operational Ac Voltage 195/230/253V
Breaking Capacity 16A 250V AC1
Max. power With Incandescent Lamps 2300W
Type Of Connection With Screw
Acceptable Current Rating With Ac1 16A
Connection Cross-Sect.Flexible Cable 1/6mm²
Connection Cross-Sect.Rigid Cable 1.5/10mm²
Fixing Mode Din-Rail
Frequency 50/60Hz
Operating Temperature -10~55ºC
Storage Temperature -20~60ºC
Protection Grade IP 20
Package includes:
1 x TENSE DQ001 Time Switch Staircase Light Timer
