EOCR motor protectors (Used)

EOCR motor protectors (Used) in Pakistan BR1478 EOCR motor protectors (Used) Application: EOCR-SS electronic overload relay is suitable for AC 50/60Hz, voltage up to 600VAC and current up to 60A.  The product conforms to IEC60947-1 standard. Specification: Type EOCR-SS Current range 05)0.5-5A(scale 6.5A) 30)3-30A(scale 35A) 60)5-60A(scale 70A) Rated voltage 600VAC,50/60Hz Operating setting D-TIME 0.2-30 seconds O-TIME 0.2-10 seconds Accuracy Current ±10% Time ±15% of max.time set value Time characteristics Definite time Control voltage 220)Voltage free(90-260)VAC,50/60Hz    440)Voltage free(320-480)VAC,50/60Hz    Other voltage optional. Current sensing 2 CTs Output contacts Contacts SPDT 3A/250AVC Resistive Contacts N  Type Normally energized :9598closed R  Type Normally De-energized:95  98closed Reset Manual or remote electrical by interrupting supply Environment Temp.Run Run -20+70 deg. o C Store -30+80 deg. o C Humidity 45-85% RH,non-condsing Insulation Between casing and circuits:Over 10M?with DC 500V meager Dielectric strength 1)Between casing and circuits:AC 2000V,60Hz,1min 2)Between contacts: AC 1000V,60Hz,1min 3)Between circuits:AC 2000V,60Hz .1min
