CH102 Digital Display PID Intelligent Temperature Controller in Pakistan

The function block Intelligent Temperature Controller calculates the flow temperature based on the outside temperature and the integrated heating curve, as well as the energy requirements of the assigned rooms . Specification: Outline(mm): 102:48*48   402:48*96  501:96*48   702:72*72 902:96*96 Control type: 0:PID control        1: step control Input type: 1:thermocouple input       2:RTD input Output type: 1: break output Refrigerating type: 0:no refrigerating    1: step refrigerating   2:proportional refrigerating Alarm type: 0:no alarm    1:upper limit alarm    2:low limit alarm Input type: 1:K     2:E    3:Pt100     4:Cu50     6:J Output type: 1:relay contact switch output    2:logic level output(used to control SSR)   3:4-20mA Alarm output: 1: 1 alarm output   2:2 alarm output Power supply: 90-260VAC or 24VDC Package includes: 1 x CH102 Digital Display PID Intelligent Temperature Controller
