Product Description
The Autonics TZN4W is an essential controller. First , it offers dual PID auto-tuning control, consequently ensuring precise temperature regulation. Moreover , the unit boasts a high-speed sampling cycle (100ms). Therefore , it provides rapid response. Furthermore , it supports various input sensors. In addition , it features alarm outputs. Hence , operation is safer. Similarly , the display is clear. Yet , it remains easy to program. Finally , choose the TZN4W because it is reliable. Indeed , this model is a standard. However , proper setup is key. Next , consider its compact size. Likewise , maintenance is straightforward. To summarize , it's a versatile tool. Altogether , a top choice.
Features of the Autonics TZN4W Temperature Controller:
Dual PID Auto-Tuning Control: Features two separate PID control groups (High-speed mode and Standard mode) for optimized response and stability.
High-Speed Sampling: Achieves rapid control with a 100ms sampling cycle.
Multi-Input Support: Compatible with 13 types of thermocouples (K, J, T, R, S, B, etc.) and 5 types of RTD (Pt100, DPt100).
Dual Display: Simultaneous display of Present Value (PV) and Setpoint Value (SV).
Output Options: Supports various control outputs including Relay, SSR drive, and Current (4-20mA).
Alarm Functions: Includes multiple alarm output types (e.g., deviation, absolute value).
Specification:
Display: Dual 4-digit 7-segment LED (Red for PV, Green for SV).
Size: W 48 x H 48 mm (DIN 1/16 size).
Power Supply: 100-240 VAC 50/60 Hz (standard).
Control Method: PID auto-tuning, PID fixed, or ON/OFF control.
Measurement Accuracy: ± 0.5% of F.S. (Full Scale) ± 1 digit.
Ambient Operating Conditions: − 1 0 ∘ C to 5 0 ∘ C .
Uses:
Industrial Ovens and Furnaces
Plastic Injection Molding Machines
Packaging and Sealing Equipment
Food and Beverage Processing (e.g., sterilization, pasteurization)
Environmental Testing Chambers
Benefits:
Process Stability: Dual PID algorithm minimizes temperature overshoot and undershoot, improving product quality.
Energy Efficiency: Precise control leads to less heating/cooling cycle fluctuation, saving energy.
Flexibility: Wide sensor compatibility allows for use in diverse applications without changing the controller model.
Reliability: Durable design suitable for harsh industrial environments.
Package includes:
1x Autonics TZN4W Temperature Controller
