A soft starter is a solid-state system or device that protects AC electric motors from damage caused by sudden influxes of power by limiting the large initial inrush of current associated with motor startup . They provide a gentle ramp up to full speed and are used only at startup (and stop, if equipped).
https://youtu.be/FReoy8R_EMA
Specifications:
Brand: ABB
Model Name/Number: PSR3-600-70
Voltage: 415V AC
Frequency: 50Hz
Dimensions (W x D x H): 45 x 140 x 114 mm
Weight: 0.4 Kg
Communication: Filed Bus Plug
Terminal Type: Screw Terminals
Connecting Capacity Main Circuit: Rigid 1/2x0.75 to 2.5 mm2
Tightening Torque: Main Circuit 1 Nxm, Supply Circuit 1 Nxm, Control Circuit 1 Nxm
Operating Temperature: n -25 to +60 degrees C
Rated Operational Voltage:
208 ... 600 V AC
Rated Control Supply Voltage (U s ):
100 ... 240 V AC
Rated Control Circuit Voltage (U c ):
24 V DC
Rated Frequency (f):
50/60 Hz
Main Circuit 50 / 60 Hz
Rated Operational Power - In-Line Connection (Pe):
(230 V) 0.75 kW
(400 V) 1.5 kW
(500 V) 2.2 kW
Rated Operational Current - In-Line Connection (Ie):
3.9 A
Package Include:
1 x ABB Soft Starter PSR3-600-70 Lotted
